Metadata & UI Integration

This section explains how to use the SaveMeta class to build a Save/Load menu. You'll learn how to display save information to the player without the performance cost of loading the actual save data.

Core Concepts

The Metadata Snapshot

When the SaveManager initializes, it doesn't load save data, but it only retrieves the small header objects called SaveMeta.

  • Performance Listing 100 saves is nearly instant, because the heavy savegames stay on disk.
  • Access All discovered saves are available via SaveManager.Instance.SaveMetas

Built-in & Custom Metadata

A save slot usually needs more than just a name. We differentiate between

  • Default Data Save Name, Display Name, Date/Time and the IsAutoSave flag
  • Custom Data Project specifc info, like "Current Location", "Player Level", "Completion Percentage"

Custom Metadata

While the default SaveMeta provides the basics (Name, Date/Time, etc.), most games require more specific information to show in a Save-Slot UI.

FlaxSave provides a straight-forward integration to attach additional information (i.e. player location, current skill level or quest progression) to a SaveMeta entry.

Custom Metadata Guide

Checkout the Custom Metadata Guide for more information.

Defining your Metadata

To store custom information, create a simple class that wraps the data you want to show in your Save-Slot UI.

C#
public class MySaveInfo
{
    public string LocationName;
    public int PlayerLevel;
    public float CompletionPercentage;
}

Attaching Data during Save

When you request a save, you can pass your custom class object directly into the RequestGameSave method. The SaveManager will serialize the class and store it inside the SaveMeta file.

C#
public void SaveTheGame()
{
    var customInfo = new MySaveInfo()
    {
        LevelName = "The Darkest Dungeon",
        PlayerLevel = 5,
        CompletionPercentage = 42.7f
    };

    // This data is now attached to the savegames metadata
    SaveManager.Instance.RequestGameSave("SaveSlot_01", customInfo);
}

Retrieving Data for the UI

When building your load menu, you can access your data directly from a SaveMeta entry. Use the GetCustomData<T>() method to safely cast the stored object back into your data class.

C#
public void BuildLoadMenu()
{
    foreach (SaveMeta meta in SaveManager.Instance.SaveMetas)
    {
        // Extract the custom data
        var customInfo = meta.GetCustomDataAs<MySaveInfo>();

        if (customInfo != null)
        {
            // Update your UI elements
            Debug.Log($"Location: {customInfo.LevelName} | Level: {customInfo.PlayerLevel}");
        }
    }
}

Performance

Custom metadata is stored as a JSON-string within the small .meta file. Because this file is separate from the large savegame files, you can create rich, informative save lists with zero lag.

Building UI & Notifications

In this example, we're going to build an endless, dynamic list of save-slots which are a staple of RPGs, Survival and Simulation games.

Every slot in the list is a UI Widget linked to a specific SaveMetas entry.

Ready-to-use Examples

You can find the complete implementation in the plugin folder:

  • Widget Prefab in FlaxSave > Content > Example
  • Logic & Scripts in FlaxSave > Source > FlaxSaveExamples

1. Create a UI Widget

UI Widget Setup For this example, the UI Widget consists of a Button, with three Label children. The labels will display:

  • DisplayName
  • SaveVersion
  • SaveDate

Convert the setup into a prefab.

2. Create the Save-Slot Logic

Create and attach a script (i.e. SaveSlot) to your Widget prefab. This script will fill the UI with the data from a SaveMeta object and handle the click event, to trigger a savegame load.

C#
public class SaveSlot : Script
{
    public ControlReference<Button> LoadButton;
    public ControlReference<Label> SavetTitelLabel;
    public ControlReference<Label> VersionLabel;
    public ControlReference<Label> DateLabel;

    private SaveMeta saveMeta;

    // Sets up the ui
    public void Bind(SaveMeta metaData)
    {
        saveMeta = metaData;

        // The friendly name of the savegame
        SavetTitelLabel.Control.Text = saveMeta.DisplayName;

        // Display the savegame Version
        VersionLabel.Control.Text = saveMeta.SaveVersion.ToString();

        // Display the time and date, when this savegame was created
        DateTime localTime = saveMeta.SaveDate.ToLocalTime();
        DateLabel.Control.Text = localTime.ToString("g");

        // Subscribe to the button clicked event
        LoadButton.Control.Clicked += LoadSave;
    }

    // Request a savegame load with the SaveName from the associated save meta
    public void LoadSave()
    {
        SaveManager.Instance.RequestGameLoad(saveMeta.SaveName);
    }

    public override void OnDisable()
    {
        // Don't forget to unsubscribe from events!
        LoadButton.Control.Clicked -= LoadSave;
        base.OnDisable();
    }
}

Remember to save changes to your prefab.

3. Scene Setup

Scene Setup For the list in the UI itself, create a UICanvas and add a child UIControl with the type set to VerticalPanel.

The advantage of a VerticalPanel is that it handles the layout for you: all children (your Save-Slot Widgets) will automatically be arranged into a clean vertical list as they are spawned. This keeps your UI organized and responsive without manual positioning.

4. Create the List Logic

Create and attach a script (i.e. SaveListManager) to the VerticalPanel control.

This script spawns the UI Widgets as children of a VerticalPanel. To keep the UI in sync with the SaveMetas, we use the OnSaved and OnDeleted events.

C#
public class SaveListManager : Script
{
    public Prefab Widget;
    public ControlReference<VerticalPanel> ListContainer;


    // Instantiates UI widgets with meta infos about savegames
    public void SpawnWidgets()
    {
        // Clear everything to avoid double entries
        Actor.DestroyChildren();

        // Instance a widget for every SaveMeta entry in the SaveManager.
        for (int i = 0; i < saveManager.SaveMetas.Count; i++)
        {
            Actor newWidget = PrefabManager.SpawnPrefab(Widget, ListContainer);
            newWidget.GetScript<SaveSlot>()?.Bind(saveManager.SaveMetas[i]);
        }
    }


    public override void OnEnable()
    {
        saveManager = SaveManager.Instance;

        // Automatically refreshes UI when as save is created or deleted
        SaveManager.Instance.OnSaved += SpawnWidgets;
        SaveManager.Instance.OnDeleted += SpawnWidgets;

        // Initial build of the UI
        SpawnWidgets();
    }

    public override void OnDisable()
    {
        // Don't forget to unsubscribe your methods from events!
        SaveManager.Instance.OnSaved -= SpawnWidgets;
        SaveManager.Instance.OnDeleted -= SpawnWidgets;
    }
}

Whenever you request a game save or an auto-save happens, the Save-Slot UI will automatically update and you can click the Button of the UI Widget to load a previous game state.

Best Practices

Notifications

Since data collection happens in the background, trying to show a a "Game Saved!" notification directly inside OnSaving will be rejected by the engine.

Use the InvokeOnSaved helper to trigger notifications, as the helper waits for the background work to finish, before executing any action on the main-thread.

The same concept goes for InvokeOnLoaded and InvokeOnDeleted.

C#
public void QuickSave()
{
    // This ensures the notification happens on the UI thread
    // only AFTER the file is safely written to disk.
    SaveManager.Instance.InvokeOnSaved(() => {
        Debug.Log("Game Saved successfully!");
    });

    SaveManager.Instance.RequestGameSave("QuickSave");
}

UI Refreshing

Don't refresh your UI list every frame. Only rebuild the list, when something actually changes. By subscribing to the SaveManager events, your UI stays reactive without wasting performance.

  • OnSaved: Refresh, when a new save is created.
  • OnDeleted: Refresh, when a save is removed (to avoid ghost-slots)
  • OnLoaded: Close the menu and trigger scene transition, once the data is ready

Localization

Use Localization Keys in the SaveMeta.DisplayName for automated entries, like auto-saves and quick-saves. By using a LocalizationString, you can attempt to translate these keys, while still gracefully falling back to the raw string, if the user provided a custom name for a manual save.

C#
public void Bind(SaveMeta metaData)
{
    // This tries to return the localized version of DisplayName.
    // If no localization key matches, it falls back to the raw value.
    var displayText = new LocalizationString()
    {
        Id = metaData.DisplayName,
        Value = metaData.DisplayName
    };

    SavetTitelLabel.Control.Text = displayText;
}


When displaying the SaveDate, use the C# built-in formatting and ToLocalTime, to respect the user's regional settings and time zone.

C#
// Simple. Uses the general date/time pattern (i.e. 01/01/2026 3:00 PM)
DateLabel.Control.Text = metaData.SaveDate.ToLocalTime().ToString("g");

// Advanced. Full control using the games current culture setting
DateTime localTime = metaData.SaveDate.ToLocalTime();

string date = localTime.ToString("d", Localization.CurrentCulture);
string time = localTime.ToString("t", Localization.CurrentCulture);

DateLabel.Control.Text = date + ", " + time;

Empty Saves

Always handle the "No Saves Found" cases. If SaveManager.Instance.SaveMetas.Count == 0, display a simple label saying "No saves found!". It's a small detail that makes the UI feel finished.
